Quartz P/T Memory Gauge

In this type of instrument, the piezo sensor is combined with an RTD (Resistance Temperature Detector) type potential rod, which allows it to react more quickly to pressure and temperature.

applications
  •
DST Tests
  • Interface Tests

  • Pressure Injection Logging
  •
Production Tests
  • Pressure Build-Up Tests
  •
Pressure Gradients

specifications
ODflexible
length24 mm
pressure sensor typepiezo / quartz
temperature sensor typePT 1000
pressure measurement range10k / 15k / 20k Kpsi
temperature measurement accuracy± 0.2
temperature measurement resolution0.001
pressure measurement acuraccy± 0.03% FS
pressure measurement resolution0.0003% FS
max memory capacity2,000,000 data
max sampling interval18 hours
min sampling interval1 second
power sourcelithium battery pack
materialSS17-4PH
communicationUSB / RS232
software compatibilitywindows 8/7/XP
